BOR Carbide Grooving and Parting-Off Catalogue

BOR Carbide Grooving and Parting-Off Catalogue [Click For Download]

Grooving Inserts, Cut-Off Inserts, Threading Inserts and Tool Holders

BOR Carbide grooving and parting-off catalogue covers shallow grooving, full radius grooving, face grooving, internal grooving, cut-off, threading and back turning insert systems for CNC turning operations.

  • BCF32, BCA43, BT11, BT16, BGR, BGER, BVNF, BVC and BMB grooving insert series.
  • MGMN, MRMN, MGGN, DGN, DGR, PENTA24N, PENTA34N, BTKF and BCTP cut-off systems.
  • External, internal and face grooving tool holders with right and left hand options.
  • Threading and back turning insert families including BTTX32, BTT32, BTKFT, BTTP and BTKFB.
Download Catalogue
BOR Carbide grooving and parting-off inserts catalogue cover

Grooving and Parting-Off Product Range

The BOR Carbide grooving and parting-off range helps shops select insert width, radius, hand, holder type, Dmin, Dmax and Tmax data for turning, grooving, parting, circlip, face groove and internal groove applications.

Shallow and Full Radius Grooving

BCF32, BCA43, BT11, BT16 and BGR insert families for narrow grooves, full radius profiles and precision groove width control.

Face and Internal Grooving

BGER-DD/EE, BVNF, BVC, BSPDR, BFVC1604 and BMB series for face grooves, internal grooves and internal face grooving operations.

Parting-Off and Cut-Off

BTKF12/16, BCTP, MGMN, MRMN, MGGN, TD, DGN, DGR, BTQJ27 and PENTA insert systems for parting-off and cut-off applications.

Threading and Back Turning

BTTX32, BTT32, BTKFT and BTTP threading inserts plus BTKFB, BABS and BABW back turning inserts for compact turning operations.

Technical Catalogue Sections

Product Family Catalogue Series Selection Data
Shallow Grooving Inserts BCF32, BCA43, BT11, BT16, BGR Right and left hand codes, A, T, d, W, L and R dimensions
Internal, Face and Circlip Grooving BGER-A/B/C/D/E, BGER-DD/EE, BVNF, BVC, BSPDR, BFVC1604, BMB Dmin, Dmax, groove width, radius, holder hand and holder dimensions
Parting-Off Inserts BTKF12/16, BCTP, MGMN, MRMN, MGGN, TD, DGN, DGR, BTQJ27, PENTA24N, PENTA34N Insert width, Dmax, radius, holder height, Tmax and matching tool holder codes
Threading Inserts BTTX32, BTT32, BTKFT12/16, BTTP, BTTPA ISO metric pitch, ANSI inch thread data, 55 degree and 60 degree thread forms
Back Turning BTKFB, BABS, BABW Insert width, radius, approach angle and compatible back turning holders

For detailed dimensions, holder drawings and ordering codes, download the full BOR Carbide Grooving and Parting-Off Catalogue.

Selected Product Code Examples

Application Example Codes
Shallow grooving inserts BCF32R033, BCF32L040, BCA43R100, BT11E050, BT16E100
Full radius grooving BCF32R040-R0,20, BCA43R100-0,50, BT16E100-R050, B7GR100-R050
External and internal holders BCKTGFR1010H-16F, KBCA2020K22, BSNGR08H06, BKSPDR0010F06A
Parting-off inserts MGMN300-M/G/T/C/J/DR, MGGN200-V, DGN2002C, BPENTA24N200
Threading and back turning BTTX32R6000, BTT32R5501, BTKFT12RA60005, BTKFB12R15005, BABS15R4005

Choosing the Right Grooving Tool

When selecting a grooving or parting-off tool, the first checks are usually groove width, required radius, cutting depth, right or left hand orientation and whether the operation is external, internal or face grooving. The BOR Carbide catalogue keeps these details together with matching holder codes, so it is easier to compare shallow grooving inserts, full radius inserts, cut-off inserts, circlip tools, MGMN, MGGN, PENTA and DGN style solutions for CNC turning.
